AJT8 FER

Mersen AMP-TRAP® 2000 SmartSpot® AJT8 Current Limiting Low Voltage North American Time Delay Power Fuse, 8 A, 600 VAC, 200 kA Interrupt, J Class, Cylindrical Body
Manufacturer: Mersen
Manufacturer part number: AJT8
Availability: Expected Leadtime 15 days
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
78 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$21.33

Product Details

Brand Name

Mersen

Type

Current Limiting Low Voltage North American Time Delay

Alternate Supplier #

Grainger - 4TAR1

Description

Amp-Trap® 2000 SmartSpot® AJT fuses now provide a visual open fuse indicator. With advanced material technology the AJT fuse provides IEC type-2 no damage protection to main, feeder and branch circuits, for all types of loads - yet, they require only half the mounting space needed for 600 VAC class RK fuses. AJT's time delay characteristics are ideal for handling typical motor and transformer inrush currents, while also providing superior current limiting ability.
Mersen AMP-TRAP® 2000 SmartSpot® Power Fuse, Current Limiting Low Voltage North American Time Delay, Series: AJT, Indicating, Rejection, 8 A, 600 VAC, 200 kA Interrupt, Class: J, Ferrule Terminal, Clip Mounting, Cylindrical Body, Dual Element, Fiberglass, 13/16 in Dia x 2-1/4 in L Body

Application

Motor Circuits, Mains, Feeders, Branch Circuits, Lighting, Heaters, Transformers, Control Panels, Circuit Breaker Back-Up, Bus Duct and Load Centers Applications

Standards

CSA C22.2 No. 248.8 | DC Listed | IEC 269-2-1 | RoHS Compliant | UL 248 | UL 248-8 File No. E2137

Features

  • Solid state SmartSpot® indicator
  • Time delay for motor starting and transformer inrush
  • 300 kA interrupting rating, self certified (UL witnessed)
  • Extremely current limiting for low peak let-thru current
  • Most current limiting UL class fuse
  • Small footprint requires less mounting space and allows smaller, more economical fuse blocks
  • Easy 2-to-1 selectivity for prevention of nuisance shutdowns
  • Unique class J dimensions prevent replacement errors
  • High visibility orange label gives instant recognition
  • Metal embossed date and catalog number for traceability and lasting identification
  • Fiberglass body provides dimensional stability in harsh industrial settings
  • High grade silica filler ensures fast arc quenching
  • Tin-plated copper, silver-plated copper contact

Specifications

Amperage Rating:8 A
Body Size:13/16 in Dia x 2-1/4 in L
Body Type:Cylindrical
Class:J
Country of Origin:MX
Element:Dual
Indicating/Non-Indicating:Indicating
Interrupt Rating:200 kA
Material:Fiberglass
Mounting Type:Clip
Rejection/Non-Rejection:Rejection
Series:AJT
Terminal Type:Ferrule
Voltage Rating:600 VAC
