Name: AL100 HUB 15MM 5X2.3MM KW LOV
Brand: Lovejoy
SKU: AL100 HUB 15MM 5X2.3MM KW LOV
Availability: OutOfStock

AL100 HUB 15MM 5X2.3MM KW LOV

Actual Product May Vary From Image

Product Details

Manufacturer:

Lovejoy

Manufacturer part number:

68514449629

CBT Inventory

Vendor Inventory

Availability:

Ships in 2-4 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Lovejoy®

Type

Type AL Style 1

Description

Lovejoy® Jaw Coupling Hub, Type AL Style 1, AL100 Coupling, 15 mm Bore, 64.3 mm Diameter Hub, 53.85 mm Hub Length, 5 mm W x 2.3 mm D Keyway, 7000 rpm Maximum, 34.8 mm Length Through Bore, 5/16-18 Screw, Aluminum, Silver

Standards

ECCN EAR99

Features

Interchangeable with all hub sizes standard for the L-line and AL-line products
Finished bores passivated for additional rust protection

Specifications

Bore Diameter:	15 mm
Country of Origin:	US
Coupling Size:	AL100
Finish:	Silver
Hub Diameter:	64.3 mm
Hub Length:	53.85 mm
Keyway Size:	5 mm W x 2.3 mm D
Length Through Bore:	34.8 mm
Material:	Aluminum
Maximum Speed:	7000 rpm
Screw Size:	5/16-18
