AX78 GAT

Picture of AX78 GAT
Actual Product May Vary From Image

Product Details

Manufacturer:
Gates Corporation
Manufacturer part number:
AX78
CBT Inventory
2
Vendor Inventory
Loading...
CBT - CINCINNATI
2
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
2 in stock
Estimated dates are contingent upon manufacturer stock.
Log in for more accurate pricing
$28.42 / EA

Description

Brand Name

Gates®

Type

Heavy Duty Molded Notch

Description

Constructed with Gates® proprietary construction, this belt has a superior combination of flex and load carrying capacity, as well as less stretch resulting in less maintenance.
Gates® Tri-Power® V-Belt, Heavy Duty Molded Notch, Series: 9012, AX Section, 1/2 in Top Width, 80 in Outside Length, 5/16 in Thickness, 1 Rib, 4.138 in Diameter Minimum Pulley, -70 to 250 deg F, EPDM, Flex-Bonded Polyester Reinforced

Application

For all industrial applications, particularly where small or sub-minimal sheave diameters are required

Standards

ARPM/RMA IP-3-2/IP-3-3

Features

  • Flex-bonded cords are strongly bonded to the body of the belt resulting in equal load distribution and the absorption of bending stress without cord deterioration
  • Notches molded into the belt during manufacturing increase flexibility making this belt well suited for drives with smaller diameter sheaves
  • Belt edge is machined for even sheave groove contact resulting in smoother running, less slip and wear
  • Patented ethylene material construction provides -70 to 250 deg F temperature range to resist belt cracking

Specifications

Country of Origin:US
Material:EPDM
Minimum Pulley Diameter:4.138 in
Number of Ribs:1
Outside Length:80 in
Reinforced Material:Flex-Bonded Polyester
Section Size:AX
Series:9012
Temperature Range:-70 to 250 deg F
Thickness:5/16 in
Top Width:1/2 in

Products Specifications

Brand Name
Gates
