BP195 GAT

Predator™
Manufacturer: Gates
Manufacturer part number: BP195
Availability: Ships in 4-6 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$108.41

Product Details

Brand Name

Gates

Alternate Supplier #

91860195

Description

Made to take on your toughest jobs, Predator Single & PowerBand banded belts are the market leading heavy duty V-belts. The stronger than steel extra heavy-duty belt construction is designed to handle high horsepower motors, frequent shock loads, high heat and the harshest operating environments in extremely demanding applications. They provide extraordinary high-impact strength, capacity and wear resistance. Unique in their extreme robustness and high load carrying capability, they are unrivaled.

Features

Improved neoprene rubber compounds provide superb oil and heat resistance. Aramid tensile cord construction is pound for pound stronger than steel and can handle up to 2.2 times (or 40%) more horsepower than standard V-belts. Minimal re-tensioning reduces maintenance needs; less maintenance, less downtime. Non-rubber Bareback surfaced, specially treated extra tough cover allows momentary slippage due to excessive overloads without damaging the belt and withstands slip and shear forces at peak loads without generating excessive heat and resists foreign material penetration. Double fabric cover offers extreme abrasion and wear resistance. Gates Curves provide full contact with pulley grooves for uniform cord loading, uniform wear and increased belt life. Available on demand in matched sets (not V80® program eligible). Engineered as OE quality replacement belts for heavy duty applications exposed to pulsating loads or heavy shock loads, such as mining, agriculture, wood processing, oil feld equipment, construction, and sand/ gravel operations. Meets ARPM/RMA IP-3-2 oil and heat resistant standards and IP-3-3 static conductivity requirements. REACH and RoHS 2 compliant.

Specifications

Angle:40
Belt Back Side:Smooth
Belt Inside:Smooth
Belt/Slab:Belt
Color:Brown
Construcao:Banded
Cord Material:Aramid
Country of Origin:MX
Effective Length (in):197.9
Effective Length (mm):5027
GC Base Product:Predator® Single Belts - BP Section
Harmonized Tariff Code:4010.39.1000
Material:Polychloroprene (Neoprene)
Max Temp (°C):+82
Max Temp (F):+180
Min Temp (°C):-30
Min Temp (F):-22
Number of Ribs/Strands:1
OC (in):198.4
OC (mm):5039
Proposition 65:NO
Secao:BP
Sided:Single Sided
Static Conductive:No
Thickness (in):0.438
Thickness (mm):11
Top Width (in):0.688
Top Width (mm):17
Unitset (V80):No
