FLUKE-1507 FLU

Picture of FLUKE-1507 FLU
Actual Product May Vary From Image

Product Details

Manufacturer:
Fluke
Manufacturer part number:
FLUKE-1507
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Ships in 6-8 days.
Estimated dates are contingent upon manufacturer stock.
Log in for more accurate pricing
$891.27 / EA

Description

Brand Name

Fluke®

Alternate Supplier #

Grainger - 1BE65

Description

Fluke® Insulation Resistance Tester, 600 VAC/VDC, 200 mA, 50 to 400 Hz Frequency Response, 01 Ohm to 20 kOhm Resistance, 0.01 Ohm to 20 kOhm Resistance, +/-2% +3 Accuracy, 0.1 V Resolution, Safety Rating: Cat IV 600 V, (4) AA Alkaline Batteries Power Source, Button/Switch/Plug-In Interface, IP40 Enclosure, 8 in L x 4 in W x 2 in H Dimensions

Application

For troubleshooting, commissioning and preventative maintenance

Standards

ANSI/ISA 82.02.01 (61010-1) 2004 | CSA/CAN C22.2 No. 61010.1-04 | ECCN 3A992 | IEC/EN 61010-1 | IEC/EN 61010-1 2nd Edition Cat IV 600 V | TUV Approved

Features

  • Make repetitive tests simple and easy with the 1507's compare (pass/fail) function (only available on the 1507)
  • Repetitive or hard to reach testing is easy with the remote test probe
  • Live circuit detection prevents insulation test if voltage >30 V is detected for added user protection
  • Auto-discharge of capacitive voltage for added user protection
  • Save battery power with auto power off
  • Read measurements easily with large, backlit display
  • Cat IV 600 VAC overvoltage category rating for added user protection
  • Remote probe, test leads, probes and alligator clips included with each tester
  • Accepts optional Fluke® TPAK magnetic hanging system to free your hands for other work
  • (4) AA alkaline batteries (NEDA 15 A or IEC LR6) for at least 1000 insulation tests
  • Tester can perform at least 1000 insulation tests with fresh alkaline batteries at room temperature
  • Tester can perform at least 2500 earth bond resistance measurements with fresh alkaline batteries at room temperature
  • Discharge time < 0.5 s for C = 1 uF or less auto-discharge

Includes

Remote Probe, Test Leads, Test Probes, Alligator Clips and User Documentation

Specifications

Accuracy:+/-2% +3
Amperage Rating:200 mA
Dimensions:8 in L x 4 in W x 2 in H
Enclosure Type:IP40
Frequency Response:50 to 400 Hz
Interface:Button/Switch/Plug-In
Power Source:(4) AA Alkaline Batteries
Resistance:0.01 Ohm to 20 kOhm
Resistance Range:01 Ohm to 20 kOhm
Resolution:0.1 V
Safety Rating:Cat IV 600 V
Voltage Rating:600 VAC/VDC
