FLUKE-233 FLU

Name: FLUKE-233 FLU
Brand: Fluke
SKU: FLUKE-233 FLU
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Fluke

Manufacturer part number:

FLUKE-233

CBT Inventory

Vendor Inventory

Availability:

Ships in 6-8 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Fluke®

Type

Remote Display

Alternate Supplier #

Grainger - 4GUE6
Fastenal - 0745568

Description

Fluke® 233 remote display digital multi-meter allows you to be 30 ft away from the measurement point with the innovative wireless display. With the 233, you can perform two man jobs alone and remove the hazard from the job. Imagine the possibilities.

Fluke® Digital Multimeter, Remote Display, 1000 VDC/VAC, 10 A, 40 MOhm Measuring, 0.1 mV to 1000 VAC, 1 mA to 10 A, 5 Hz to 50 kHz Frequency, 0.1 Ohm to 40 MOhm Resistance, Safety Rating: CAT IV 600 VAC/VDC, CAT III 1000 VAC/VDC, 1 nF to 9999 uF Capacitance, 1% + 3 for VAC, 0.25% +2 for VDC Accuracy, Backlit Display, AA Alkaline Battery, Peak Hold: No, Yes Diode Test, 2.08 in L x 3.6 in W x 7.6 in H Dimensions, -40 to 400 deg C, Hard Plastic

Application

Electrical and Electronic Circuit Measurement Applications

Standards

Features

True-RMS AC voltage and current for accurate measurements on non-linear signals
Built-in thermometer conveniently allows you to take temperature readings without having to carry a separate instrument
Low power wireless technology allows the display to be carried up to 10 m away from the point of measurement for added flexibility, no interference with measurements
Removable magnetic display can be conveniently mounted where it is easily seen
Make measurements without holding the meter to improve visual focus on probes and augment safe electrical measurements
Use as a conventional multi-meter when the display is connected
Radio transmitter automatically turns off when the display is connected to the meter
Auto power off maximizes battery life
Minimum maximum and average recording to capture variations automatically
Easy to read display with large digits and bright backlight
Battery life approximately 400 hr, AC voltage 1% 3, DC voltage 0.25% 2 accuracy
Resistance range - 0.1 Ohm to 40 MOhm
Capacitance range 1 nF to 9999 uF
Frequency range 5 Hz to 50 kHz
400 hours battery life with backlight, min max average data storage, auto/manual ranging
6000 count, update 4/s (frequency 9, 999 count) display

Specifications

Accuracy:	1% + 3 for VAC, 0.25% +2 for VDC
Amperage Rating:	1 mA to 10 A
Battery Type:	AA Alkaline
Capacitance:	1 nF to 9999 uF
Dimensions:	2.08 in L x 3.6 in W x 7.6 in H
Diode Test:	Yes
Display Type:	Backlit
Frequency Rating:	5 Hz to 50 kHz
Material:	Hard Plastic
Measuring Range:	1000 VDC/VAC, 10 A, 40 MOhm
Peak Hold:	No
Resistance:	0.1 Ohm to 40 MOhm
Safety Rating:	CAT IV 600 VAC/VDC, CAT III 1000 VAC/VDC
Temperature Rating:	-40 to 400 deg C
Voltage Rating:	0.1 mV to 1000 VAC
