FLUKE-289 FLU

Name: FLUKE-289 FLU
Brand: Fluke
SKU: FLUKE-289 FLU
Price: 982.99 USD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Fluke

Manufacturer part number:

FLUKE-289

CBT Inventory

Vendor Inventory

Availability:

Ships in 6-8 days.

Estimated dates are contingent upon manufacturer stock.

$982.99 / EA

Description

Brand Name

Fluke®

Alternate Supplier #

Grainger - 1EVC3
Fastenal - 0726776

Description

Fluke® 289 is the next generation high performance industrial logging multi-meter designed to solve complex problems in electronics, plant automation, power distribution and electro mechanical equipment. With the ability to log data and review it graphically on screen, you can solve problems faster and help minimize downtime let the new 289 be your watchdog for systems or processes while you are off solving other problems.

Fluke® Digital Multimeter, 1000 VDC/VAC, 10 A, 500 MOhm Measuring, 1000 VAC/VDC, 10 A, 999.99 kHz Frequency, 500 Ohm to 50 MOhm Resistance, Safety Rating: CAT IV 600 VAC/VDC, CAT III 1000 VAC/VDC, 1 nF to 100 uF Capacitance, 0.025% VDC, 0.4% (True RMS) VAC Accuracy, 100 kHz Bandwidth, Dot Matrix Display, (6) AA Alkaline, NEDA 15 A/IEC LR6 V Battery, Peak Hold: Yes, Yes Diode Test, 2.38 in L x 4.03 in W x 8.75 in H Dimensions, -328 to 2462 deg F, Hard Plastic

Application

Solve Complex Problems in Electronics, Plant Automation, Power Distribution and Electro Mechanical Equipment Applications

Standards

CE Marking | CSA Certified | ECCN: 3A992 | TUV Approved | UL Listed

Features

TrendCapture quickly graphically displays logged data session to quickly determine whether anomalies may have occurred
Zoom on trend provides unprecedented ability to view and analyze TrendCapture data, zoom in up to 14 times
Selectable AC filter (smoothing mode) helps display a steadier reading when the input signal is changing rapidly or noisy
Adjustable recording and auto-hold thresholds, specify a percentage change in the readings that begins a new event
Large 50000 count, 1/4 VGA display with white backlight, multiple sets of measurement information can be simultaneously displayed at the same time
Logging function with expanded memory for unattended monitoring of signals over time, using on board TrendCapture users can graphically review logged readings without needing a PC
Stores up to 15000 recorded events, on board help screens for measurement function
Saved measurements allow to name and recall measurements made in the field, optional infrared connector via Fluke® IR3000 FC
Real time clock for automatic time stamping of saved readings
True-RMS AC voltage and current for accurate measurements on complex signals or non-linear loads, AC bandwidth specified to 100 kHz
Relative mode to remove test lead resistance from low Ohm or capacitance measurements, voltage DC, 0.025%, voltage AC, 0.4% (True-RMS) accuracy
Resistance range - 500 Ohm, 5 kOhm, 50 kOhm, 500 kOhm, 5 MOhm, 50 MOhm, 500 MOhm with accuracy of +/- 0.05%
Capacitance range 1 nF, 10 nF, 100 nF, 1 uF, 10 uF, 100uF, 1000 uF, 10 mF, 100 mF with accuracy of 1%
Frequency range 99.999 Hz, 999.99 Hz, 9.9999 kHz, 99.999 kHz, 999.99 kHz with accuracy of +/-0.005%
100 hour min, 200 hour in logging mode
50000 count, 1/4 VGA display with white backlight display

Specifications

Accuracy:	0.025% VDC, 0.4% (True RMS) VAC
Amperage Rating:	10 A
Bandwidth:	100 kHz
Battery Type:	(6) AA Alkaline, NEDA 15 A/IEC LR6 V
Capacitance:	1 nF to 100 uF
Dimensions:	2.38 in L x 4.03 in W x 8.75 in H
Diode Test:	Yes
Display Type:	Dot Matrix
Frequency Rating:	999.99 kHz
Material:	Hard Plastic
Measuring Range:	1000 VDC/VAC, 10 A, 500 MOhm
Peak Hold:	Yes
Resistance:	500 Ohm to 50 MOhm
Safety Rating:	CAT IV 600 VAC/VDC, CAT III 1000 VAC/VDC
Temperature Rating:	-328 to 2462 deg F
Voltage Rating:	1000 VAC/VDC
