Actual Product May Vary From Image

FLUKE-376 FC FLU

Name: FLUKE-376 FC FLU
Brand: Fluke
SKU: FLUKE-376 FC FLU
Price: 659.99 USD
Availability: InStock

Fluke® FLUKE-376/FC Wireless Clamp Meter, 999.9 A, 60 kOhm, 10 to 100/100 to 500 Hz, 34 mm Jaw

Manufacturer: Fluke

Manufacturer part number: FLUKE-376/FC

Availability: Ships in 6-8 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
1	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$659.99

Qty:

Product Details

Brand Name

Fluke®

Type

Wireless

Alternate Supplier #

Grainger - 45MU54

Description

The Fluke® 376 FC wireless True-RMS™ AC/DC clamp meter offers measurements up to 1000 VAC and 1000 A, AC or DC, plus an included iFlex" flexible current clamp.

Fluke® Clamp Meter, Wireless, 999.9 A Electrical Rating, 60 kOhm Resistance, 10 to 100/100 to 500 Hz Frequency, 34 mm Jaw, 2% +/-5 Digits, 2.5% +/-5 Digits, 3% +/-5 Digits AC Current Accuracy, 1.5% +/-5 Digits, 1% +/- 5 Digits Voltage Accuracy, Frequency Counter: 5 to 500 Hz, Safety Rating: CAT IV 600 VAC, CAT III 1000 VAC, (2) AA NEDA 15A IEC LR6 Batteries Power Source, 14 to 122 deg F Operating, 249 mm L x 85 mm W x 45 mm H Dimensions

Standards

CE Marking | CSA Certified | ECCN: 3A992 | TUV Approved

Features

Connect your meter to your smartphone with Fluke® connect measurements
Read measurements on your phone at a safe distance, wearing less PPE while your meter takes all the risks
Record results directly to your phone and the cloud
Capture intermittent faults while performing other tasks using the logging capabilities of the Fluke® 376 FC
Create and share reports from the field via email or converse in real time with share live video calls
IFlex® flexible current probe expands the measurement range to 2500 A AC, provides access to large conductors in tight spaces
Proprietary inrush measurement technology to filter out noise and capture motor starting current exactly as the circuit protection sees It
-40 to 60 deg C storage temperature
IP30 protection rating
600 A AC and DC current measurement
2500 A AC current measurement with iFlex® flexible current probe
1000 VAC/VDC voltage measurement
True-RMS voltage and current for accurate measurements on non-linear signals
Resistance measurement to 6000 Ohm with continuity detection
600 A AC current via jaw/2500 A AC current via flexible current probe
0.1 A resolution via jaw/flexible current probe
1% +/-5 digits resistance accuracy
1000 uF capacitance measurement
0.1 uF </=100 uF, 1 u F </=1000 uF resolution capacitance
Log and trend measurements and pinpoint intermittent faults

Specifications

AC Current Accuracy:	2% +/-5 Digits, 2.5% +/-5 Digits, 3% +/-5 Digits
Country of Origin:	CN
Dimensions:	249 mm L x 85 mm W x 45 mm H
Electrical Ratings:	999.9 A
Frequency Counter:	5 to 500 Hz
Frequency Rating:	10 to 100/100 to 500 Hz
Jaw Capacity:	34 mm
Operating Temperature:	14 to 122 deg F
Power Source:	(2) AA NEDA 15A IEC LR6 Batteries
Resistance:	60 kOhm
Safety Rating:	CAT IV 600 VAC, CAT III 1000 VAC
Voltage Accuracy:	1.5% +/-5 Digits, 1% +/- 5 Digits
