G1018 BOS

Boston Gear® G1018 Plain Worm Gear, 48 Pitch, 14.5 deg Angle, 1 Thread, Right Hand Rotation, 20 Teeth, 0.417 in Pitch, 0.188 in Bore, 0.156 in Face, Bronze
Manufacturer: Boston Gear
Manufacturer part number: G1018
Availability: Ships in 3-5 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$41.48

Product Details

Brand Name

Boston Gear®

Type

Plain

Description

Boston Gear® worm gears provide effective power transmission in applications requiring high ratio speed reduction in a limited space using right angle (90 deg), non-intersecting shafts. They are also the smoothest, quietest form of gearing when properly applied. Boston Gear® offers worm gears manufactured from a variety of materials, such as acetal, minlon, bronze and cast iron to suit your application's requirements. The efficiency of a worm gear drive depends on the lead angle and number of starts on the worm, the ratio should be kept low. To run properly, worms and worm gears operating together must have the same diametrical pitch and threads.
Boston Gear® Worm Gear, Plain, Series: G Series, 0.188 in Bore, 0.47 in Outside Dia, 20:1 Gear Ratio, 1 Number of Threads, 20 Teeth, 48 Diametral Pitch, 0.417 in, 0.156 in Face Width, Right Hand Direction of Rotation, 0.34 in Hub Dia, 0.19 in Hub Projection, 0.346 in Overall Length, 14.5 deg Pressure Angle, Bronze

Standards

PROP65: This product contains lead, known to the State of California to cause cancer and birth defects or other reproductive harm.

Features

  • 90 deg non intersecting shaft applications
  • Smoothest and quietest form of gearing
  • High ratio speed reduction
  • Minimal space requirements
  • Resistance to back driving with some ratios
  • Increased efficiency with lower ratios
  • Self locking
  • Without hardened teeth

Specifications

Country of Origin:US
Diametral Pitch:48
Direction of Rotation:Right Hand
Face Width:0.156 in
Gear Ratio:20:1
Hub Diameter:0.34 in
Hub Projection:0.19 in
Material:Bronze
Number of Teeth:20
Number of Threads:1
Outside Diameter:0.47 in
Overall Length:0.346 in
Pitch Diameter:0.417 in
Pressure Angle:14.5 deg
Series:G Series
