GFRST15GY HWD

Name: GFRST15GY HWD
Brand: Hubbell Wiring Device-Kellems
SKU: GFRST15GY HWD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Hubbell Wiring Device-Kellems

Manufacturer part number:

GFRST15GY

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Wiring Device-Kellems

Type

1-Phase Grounding Self-Test Screw Mount

Description

Wiring Device-Kellems GFCI Receptacle, Auto Decorator Grounding Standard Straight Blade, 125 VAC, 20 A, 1/2 hp, 60 Hz Frequency, 2 Pole, 3 Wires, NEMA 5-20R NEMA Rating, Commercial Grade, -35 to 66 deg C, Back/Side Wire Terminal, Nylon, Gray, 3.27 in H x 1.75 in W x 1.47 in D Dimensions

Application

Power Protection Applications

Standards

UL 498, 943 | CSA Certified | ADA NEC | NEMA WD6 | RoHS Compliant

Features

Patented AUTOGUARD self-test technology includes disconnecting power to the receptacle if critical components are damaged and GFCI protection is lost
Internal back wiring clamp and guide for quick and secure termination
Night light option includes light sensor controls for automatic ON and OFF, custom dual lens for optimum light output
Brass power contacts and ground contacts
Zinc plated steel mounting strap and mounting screws
Terminal screws connection
Triple wipe construction

Specifications

Amperage Rating:	15 A
Color:	Gray
Country of Origin:	CN
Dimensions:	1.75 in W x 1.47 in D x 3.27 in H
Frequency Rating:	60 Hz
Grade:	Commercial
Horsepower:	1/2 hp
Material:	Nylon
NEMA Rating:	5-15R
Number of Poles:	2
Number of Wires:	3
Temperature Rating:	-35 to 66 deg C
Terminal Type:	Back/Side Wire
Voltage Rating:	125 VAC
