GUBBD317 APN

Picture of GUBBD317 APN
Actual Product May Vary From Image

Product Details

Manufacturer:
Appleton
Manufacturer part number:
GUBBD317
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Expected Leadtime 7 days
Estimated dates are contingent upon manufacturer stock.
Price on Request

Description

Brand Name

Appleton®

Type

Dust-Ignitionproof Explosionproof

Description

Appleton® explosionproof, dust-ignitionproof GUBB, GUBBD and GUBBM cast junction boxes are designed for use where the number and size of conductors require a junction box with additional space. They are ideal for use in indoor and outdoor classified locations. These corrosion-resistant junction boxes provide access for maintenance. They can be used as pull boxes for pulling and splicing of wires and as an enclosure for electrical devices.
Appleton® Cast Junction Box, Dust-Ignitionproof Explosionproof, Series: GUBBD, Lug Mounting, For Use With: UNILETS® Threaded Metal Conduit, Malleable Iron, Triple Coated, 12 in L x 14.38 in W x 25.31 in D Dimensions

Application

Indoor and Outdoor Applications

Standards

UL 886 (UL 1203), UL File No. E85310 | CSA C22.2 No. 25, C22.2 No. 30 | CSA File No. 025875 | NEC/CEC Class I, Division 1 and 2, Group D, Class II, Division 1 and 2, Groups E, F, G, Class III

Features

  • Accurately tapped, tapered conduit threads for tight, rigid joints and ground continuity
  • All conduit hubs and openings provide a minimum of five full threads to meet UL requirements
  • Provided with mounting lugs and covers
  • O-rings standard to provide raintight fit
  • GUBBD series junction boxes with dome cover and mounting plate provide flexibility for a wide variety of applications
  • Ideal for housing relays, contactors, terminal blocks and other classified area applications
  • Mounting plate can be drilled to accommodate a variety of devices
  • The dome cover has nominal depth of 6 in or 17 in, depending upon box selected, it provides a significant increase in cub

Specifications

Country of Origin:US
Dimensions:12 in L x 14.38 in W x 25.31 in D
Finish:Triple Coated
Material:Malleable Iron
Mounting Type:Lug
Series:GUBBD
Suitable For Use With:UNILETS® Threaded Metal Conduit
