HBL2182OW HWD

Name: HBL2182OW HWD
Brand: Hubbell Wiring Device-Kellems
SKU: HBL2182OW HWD
Price: 44.14 USD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Hubbell Wiring Device-Kellems

Manufacturer part number:

HBL2182OW

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

$44.14 / EA

Description

Brand Name

Wiring Device-Kellems

Type

1-Phase Decorator Duplex Grounding Standard

Description

Wiring Device-Kellems HBL® Style Line® Straight Blade Receptacle, 1-Phase Decorator Duplex Self-Grounding Standard Screw Mount, 125 VAC, 20 A, 1 hp, 2 Pole, 3 Wires, 5-20R NEMA Rating, Hospital Grade, IP20 Enclosure, -40 to 75 deg C, Back and Side Wire/Screw Terminal, Nylon, Office White, 3.28 x 1.36 x 1.03 in

Application

Dry Indoor Applications

Standards

Features

HBL® extra heavy duty hospital grade receptacle
Aesthetic Style Line® decorator design
Impact resistant thermoplastic construction
Triple wipe contact
Nylon face and PBT base
0.031 in brass ground contact
Nickel plated steel clamping plate, brass terminal screw, 0.05 in galvanized steel mounting strap, stainless steel automatic self grounding staple, zinc plated steel mounting screw
Certified for current interrupting at full rated current
Withstands 2000 VAC minimum dielectric voltage
12 to 10 AWG stranded or solid copper wire only
Screw mounted

Specifications

Amperage Rating:	20 A
Color:	Off-White
Country of Origin:	PR
Dimensions:	3.28 x 1.36 x 1.03 in
Enclosure:	IP20
Grade:	Hospital
Horsepower:	1 hp
Material:	Composite/Thermoplastic
NEMA Rating:	5-20R
Number of Poles:	2
Number of Wires:	3
Temperature Rating:	-40 to 75 deg C
Terminal Type:	Back and Side Wire/Screw
Voltage Rating:	125 VAC
