HBL4100P7W HWD

Name: HBL4100P7W HWD
Brand: Hubbell Wiring Device-Kellems
SKU: HBL4100P7W HWD
Price: 734.23 USD
Availability: InStock

Wiring Device-Kellems Circuit-Lock® HBL4100P7W 3-Phase Grounding Heavy Duty Male Standard Watertight Pin and Sleeve Plug, 480 VAC, 100 A, 3 Poles, 4 Wires, Red

Manufacturer: Hubbell Wiring Device-Kellems

Manufacturer part number: HBL4100P7W

Availability: Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
1	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$734.23

Qty:

Product Details

Brand Name

Wiring Device-Kellems

Type

3-Phase Grounding Heavy Duty Male Standard Watertight

Description

Wiring Device-Kellems Circuit-Lock® Pin and Sleeve Plug, 3-Phase Grounding Heavy Duty Male Standard Watertight, 480 VAC, 100 A, 3 Poles, 4 Wires, Industrial Grade, IP67 Enclosure, -40 to 75 deg C, Pressure Screw Terminal, Composite, Red, 12.63 in L x 4.92 in W

Application

High Ampacity Connection Applications

Standards

RoHS Compliant | IEC 309-1/309-2 | UL 498 File No. E146032 | CSA C22.2 File No. 182.1 | IEC 60309-1

Features

1-piece non-metallic housing provides impact and chemical resistance in an insulated body
Solid 1-piece pins for reliable electrical contact
Gasketed sealing ring provides watertight seal when mated with receptacle or connector
Heavy duty external cord grips for maximum cord retention
High impact thermoset retainer and contact carrier
Stainless steel (300 series) terminal and assembly screws
Rynite SST35 cord clamp and solid neoprene grommet/glands
Nickel plated brass clamp nut
Withstands 3000 VAC minimum dielectric voltage
Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% rated current for either AC or DC applications per UL 498 temperature rise
Terminals identified in accordance with North American and IEC conventions terminal identification
Identification and ratings are a permanent part of the device housing
Watertight per IEC 60309-1 moisture resistance
Reinforced thermoplastic polyester locking ring, solid neoprene sealing gasket
3 to 1/0 AWG wire size
All portable cord
Cord mounted
Non-NEMA rating

Specifications

Amperage Rating:	100 A
Color:	Red
Country of Origin:	US
Dimensions:	12.63 in L x 4.92 in W
Enclosure:	IP67
Grade:	Industrial
Material:	Composite
Number of Poles:	3
Number of Wires:	4
Temperature Rating:	-40 to 75 deg C
Terminal Type:	Pressure Screw
Voltage Rating:	480 VAC
