HPMS04150 HWD

Name: HPMS04150 HWD
Brand: Hubbell Wiring Device-Kellems
SKU: HPMS04150 HWD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Hubbell Wiring Device-Kellems

Manufacturer part number:

HPMS04150

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Wiring Device-Kellems

Type

Standard

Description

Wiring Device-Kellems Mini-Quick® Control Plug, Straight Male Connector, 7/8-16 UN Connector, SEOOW Cable, 50 ft Cable Length, PVC Cable, 4 Pole, 600 VAC/VDC, 12 A, Wire Pin Colors: Black/Green/Red/White, NEMA 4/4X/12/13

Application

For quick connect/disconnect signal and control

Standards

RoHS Compliant | UL 2238/50 File No. E192071 | CSA C22.2 No. 182.3/94.2-07 | cULus Listed

Features

Nickel plated brass coupling nuts and receptacle shells
Black overmold and cable
Insulgrip connector body design
Plating resists corrosion in high abuse environments
Cable assembly resists dirt and blends with environment giving a clean look to the installation
Third party certified for electrical, mechanical and environmental performance
Ergonomic connector body has an industrial look
Gated strain relief with graduated window sizes improves flexibility, strength and protects wire terminations, superior arc of bend control
Leaded nickel copper sleeved contact extends contact life and continuity
O-rings for moisture protection
Anti-vibration coupling nut prevents connection from loosening under harsh vibration conditions
Indicator ring ensures proper mating

Specifications

Amperage Rating:	12 A
Cable Length:	50 ft
Cable Material:	PVC
Cable Type:	SEOOW
Connector Material:	Nickel Plated Brass
Connector Size:	7/8-16 UN
Connector Type:	Straight Male
Country of Origin:	US
IEC Rating:	IP67
NEMA Rating:	NEMA 4/4X/12/13
Number of Poles:	4
Voltage Rating:	600 VAC/VDC
Wire Pin Colors:	Black/Green/Red/White
