IE-110 SHD

ACTIVE TRK FILTER 1PH 10A 120V DIN
Manufacturer: SolaHD (Emerson)
Manufacturer part number: IE-110
Availability: Ships in 4-6 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 4
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$425.83

Product Details

Brand Name

SolaHD

Type

Surge Protective Devices

Description

Islatrol IE Series Active Tracking Filter, 120 V/Continuous Current 10 Amps

Application

Critical industrial loads drawing up to 20 Amps of continuous current, microprocessor-based products, including industrial PLCs, OEM applications, and motion control systems.

Standards

ANSI/UL 1449 Third Edition Type 4,1283, CUL recognized, CE, ROHS

Features

Surge current capacity 45,000 Amps; Transient protection in all modes: line to neutral, line to ground, and neutral to ground; LED status indication and form C contact for remote indication; DIN mountable enclosure

Specifications

Amperage Rating:5 A
Class:Category A Ringwave (6kv, 200 A, 100 kHz)
Connection:IEC 998 approved terminals
Country of Origin:MX
Environmental Conditions:Humidity: 0 to 95%
Frequency Rating:47-63 Hz
Mounting:DIN/Flange
Operating Temperature:-40 DEG C to +45 DEG C at Full Load; Derate Linearly to 60% at +70 DEG C
Phase:1
Response Time:Normal Mode <0.5ns; Common Mode <5ns
Short Circuit Rating:Surge current capacity - 45,000 Amps
Size:4.06 Length x 3.06 Width x 3.83 High IN
Sub Brand:Edco
Type of Indicators:LED Power Indicators
Voltage Rating:120 V
