J219773 FER

Mersen J219773 Type gG Cylindrical Low Voltage Fuse Link, 500 VAC, 125 A, Ceramic
Manufacturer: Mersen
Manufacturer part number: J219773
Availability: Expected Leadtime 50 days
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 8 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$36.00

Product Details

Brand Name

Mersen

Type

Type gG Cylindrical Low Voltage

Description

MERSEN aM and gG fuse links cover a wide range of physical sizes and ampere ratings for 400, 500, and 690 VAC for protection in electrical distribution circuits and various industrial applications. Most ratings are available in size 8x31 and size 10x38 with an optional indicator, and in size 14x51 and 22x58 with an optional striker to activate an auxiliary contact. Size 10x38 is also available with striker. All cylindrical fuse links have ceramic bodies and silver plated contacts. Cylindrical fuse links gG are used for the protection of cables, motors and LV-networks. They limit and cut-off unacceptable overcurrents and short circuit currents up to their nominal breaking capacity. Cylindrical fuse links gG also protect electrical equipment and installations against the dynamic effect of high short-currents. Our technology and process was designed to ensure highly reliable technical performance.
Mersen Fuse Link, Type gG Cylindrical Low Voltage, 500 VAC, 125 A, 11.3 W, 50 Hz, Rated Breaking Capacity: 120 kA, Clip Mount, Ceramic, 22.2 mm Dia x 58 mm L

Application

For protection of line, cable against overload and short circuit in various industrial application and electrical distribution circuits

Standards

RoHS Compliant | IEC 60269-1 | IEC 60269-2 | CE Certified | EAC Approved | REACH Compliant | KR Certified | LR Certified | DNV-GL Certified | BV Certified

Features

  • Without indicator
  • Reduced size
  • Full range protection
  • Safest and most reliable protection system

Specifications

Amperage Rating:125 A
Country of Origin:TN
Dimensions:22.2 mm Dia x 58 mm L
Frequency Rating:50 Hz
Material:Ceramic
Mounting Type:Clip
Power Rating:11.3 W
Rated Breaking Capacity:120 kA
Voltage Rating:500 VAC
