KH12-PP INA

INA KH12-PP KH..-PP Linear Ball Bushing Bearing, Closed Closure, 12 mm Dia Shaft, 19 mm OD, 28 mm L
Manufacturer: INA
Manufacturer part number: KH12-PP
Availability: Ships in 3-5 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$38.63

Product Details

Brand Name

INA

Description

INA linear ball bearings of series KH are linear recirculation ball bearing units of very small radial section height. They consist of a drawn and hardened outer cup and a plastic cage. The outer cup, cage and balls form a closed linear bearing which is ready to assemble. These units are suitable for applications where long travel distances, low space requirements and predominantly maintenance free operation are required.
INA Linear Ball Bushing Bearing, Series: KH..-PP, 12 mm Shaft Dia, 19 mm Outside Dia, 19 mm Height, 28 mm Length, 19 mm W, Closed Closure, 670 to 800 N Dynamic/510 to 740 N Static, Alloy Steel Bearing, Polyester Elastomer Seal, Linear Lube Lubrication, -30 to 80 deg C

Features

  • Very small radial section height
  • Axial location is not required
  • Optimum sealing
  • Lubricant is retained in the bearing

Specifications

Bearing Material:Alloy Steel
Closure Type:Closed
Height:19 mm
Length:28 mm
Load Capacity:670 to 800 N Dynamic/510 to 740 N Static
Lubrication Type:Linear Lube
Outside Diameter:19 mm
Seal Material:Polyester Elastomer
Series:KH..-PP
Shaft Diameter:12 mm
Temperature Rating:-30 to 80 deg C
Width:19 mm
