LA100P40-4 LIT

Name: LA100P40-4 LIT
Brand: Littelfuse
SKU: LA100P40-4 LIT
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Littelfuse

Manufacturer part number:

LA100P40-4

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Littelfuse®

Type

High Speed Very Fast Acting

Description

Littelfuse® LA100P semiconductor protection fuses are rated 1000 VAC, extending the range of protection for UPS systems, AC and DC drives, reduced voltage motor starters and similar applications where lower I2t and superior reliability are needed. With ratings from 15 to 1000 A, a wide range of high voltage applications can be served.

Littelfuse® POWR-GARD® Semiconductor Fuse, High Speed Very Fast Acting, Series: LA100P, 40 A, 1000 VAC, 750 VDC, 10 kA Interrupt, Bolt-In/Blade Mounting, Cartridge/Round Body, 1 in Dia x 5 in L Body

Application

For protection of UPS systems, AC/DC drives, reduced voltage motor starters and other 1000 VAC or less semiconductor devices, electrical and industrial applications

Standards

UL Recognized

Features

Lowest I2T minimizes damage to protected components on short circuit
Controlled arc voltage reduces stress to circuit components during fuse clearing

Specifications

Amperage Rating:	40 A
Body Size:	1 in Dia x 5 in L
Body Type:	Cartridge/Round
Country of Origin:	MX
Interrupt Rating:	10 kA
Mounting Type:	Bolt-In/Blade
Series:	LA100P
Voltage Rating:	1000 VAC, 750 VDC
