LAM2A800-58-6Y PAN

Name: LAM2A800-58-6Y PAN
Brand: Panduit
SKU: LAM2A800-58-6Y PAN
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Panduit

Manufacturer part number:

LAM2A800-58-6Y

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Panduit®

Description

Panduit offers a broad variety of mechanical lugs, splices, and split bolt connectors suitable for a wide range of electrical terminations using code conductor. Designed to be reusable and installed without special tooling, Pan-Lug Mechanical Connectors provide quality performance, ease of installation, and lowest installed cost.

Panduit®, LAM2A800-58-6Y, Mechanical Terminal Lug, Series: LAM2A, Copper/Stranded Aluminum Conductor, 350 to 800 kcmil Conductor, 5/8 in Stud, 2 Bolt Holes, 2-Barrel Straight Tongue, 600 VAC, 90 deg C, Tin Plated

Application

For Stranded Aluminum or Copper Code Conductors

Standards

ARRA Compliant | Buy American Act Compliant | RoHS Compliant

Features

Made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performance
Wide wire range taking capability minimizes inventory requirements
Inspection window to visually assure full conductor insertion
Plated steel or aluminum set screw provides high strength, durable electrical contact between conductor and connector
Dual barrel provides termination of two conductors
Available with NEMA hole sizes and spacing
Tin-plated to inhibit corrosion
1 stud of 5/8 in
6/Pack

Specifications

Conductor Size:	350 to 800 kcmil
Conductor Type:	Copper/Stranded Aluminum
Country of Origin:	MX
Finish:	Tin Plated
Material:	Aluminum
Number of Bolt Holes:	2
Series:	LAM2A
Stud Size:	5/8 in
Temperature Rating:	90 deg C
Tongue Type:	2-Barrel Straight
Voltage Rating:	600 VAC
