LCAX8-10H-L PAN

Name: LCAX8-10H-L PAN
Brand: Panduit
SKU: LCAX8-10H-L PAN
Price: 2.77 USD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Panduit

Manufacturer part number:

LCAX8-10H-L

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

$2.77 / EA

This product has a minimum quantity of 50

Description

Brand Name

Panduit®

Type

1-Hole

Description

Panduit®, LCAX8-10H-L, Compression Connector Lug, 1-Hole Type LCAX-H, Flexible/Code Conductor, 8 AWG Conductor, Die Code: P21, 35 kV, #10 Stud, 45 deg Tongue, 0.41 in W x 0.08 in THK Tongue, 1 in Overall Length, Standard Barrel, 0.18 in ID x 0.27 in OD x 0.42 in L Barrel, Specifications: 12.7 mm L Wire Strip, 90 deg C, 0.2 in Mounting Hole, Tin Plated Copper, Red, 0.64 in H Dimensions

Application

For class G, H, I, K, M and diesel locomotive flexible, extra flexible and code stranded copper conductors

Standards

Features

Can be used with code conductor and flex conductor class G, H, I, K, m and diesel locomotive
Generously beveled wire entry prevents bent back strands when inserting conductor into barrel
Color coded barrels marked with Panduit® and specified competitor die index numbers for proper crimp die selection
Inspection window to visually assure full conductor insertion
Tin plated to inhibit corrosion

Specifications

Barrel Size:	0.18 in ID x 0.27 in OD x 0.42 in L
Barrel Type:	Standard
Color:	Red
Conductor Size:	8 AWG
Conductor Type:	Flexible/Code
Country of Origin:	MX
Die Code:	P21
Dimensions:	0.64 in H
Material:	Tin Plated Copper
Mounting Hole Size:	0.2 in
Overall Length:	1 in
Series:	LCAX
Specifications:	1/2 in L Wire Strip
Stud Size:	#10
Temperature Rating:	90 deg C
Tongue Size:	0.41 in W x 0.08 in THK
Tongue Type:	45 deg
Voltage Rating:	35 kV
