LCD350-14B-X PAN

Name: LCD350-14B-X PAN
Brand: Panduit
SKU: LCD350-14B-X PAN
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Panduit

Manufacturer part number:

LCD350-14B-X

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

This product has a minimum quantity of 10

Description

Brand Name

Panduit®

Type

2-Hole

Description

Panduit®, LCD350-14B-X, Compression Connector Lug, 2-Hole Type LCD, 350 kcmil Conductor, Die Code: P71, 35 kV, 1/4 in Stud, Straight Tongue, 1.28 in W x 0.17 in THK Tongue, 3.3 in Overall Length, Standard Barrel, 0.7 in ID x 0.88 in OD x 1.44 in L Barrel, Specifications: 38.1 mm L Wire Strip, 90 deg C, 0.27 in Mounting Hole, Tin Plated Copper, Red

Application

For stranded copper conductors

Standards

Features

Color coded barrels marked with Panduit® and specified competitor die index numbers for proper crimp die selection
Inspection window to visually assure full conductor insertion
Tin plated to inhibit corrosion

Specifications

Barrel Size:	0.7 in ID x 0.88 in OD x 1.44 in L
Barrel Type:	Standard
Color:	Red
Conductor Size:	350 kcmil
Conductor Type:	Code Copper
Country of Origin:	MX
Die Code:	P71
Material:	Tin Plated Copper
Mounting Hole Size:	0.27 in
Overall Length:	3.3 in
Series:	LCD
Specifications:	38.1 mm L Wire Strip
Stud Size:	1/4 in
Temperature Rating:	90 deg C
Tongue Size:	1.28 in W x 0.17 in THK
Tongue Type:	Straight
Voltage Rating:	35 kV
