LDC300 LIT

Littelfuse® POWR-GARD® LDC300 Current Limiting Fast Acting Fuse, 300 A, 600 VAC/VDC, 50/200 kA Interrupt, L Class, Cartridge Body
Manufacturer: Littelfuse
Manufacturer part number: LDC300
Availability: Ships in 4-6 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$2,135.60

Product Details

Brand Name

Littelfuse®

Type

Current Limiting

Description

Littelfuse® POWR-PRO® LDC series Class L fuses represent another first in fuse protection. LDC series fuses are the first UL Listed 600 VAC and DC Class L fuse. Since they may be used for both AC and DC, they eliminate the concern that AC only fuses may be inserted into DC circuits. While LDC series fuses UL Listed DC interrupting rating is more than adequate for most applications (50000 A at a 16 msec time constant), tests in our high power testing laboratory have shown that this remarkable fuse is capable of performing at much longer time constants. This makes the fuse uniquely suited for such applications as crane rail circuits and mass transit systems. Contact the factory for application information for special needs such as this. For AC only systems, consider the use of POWR-PRO® KLPC series fuses. They have a full ten seconds time delay at 500% rated current, and have a wider range of ratings.
Littelfuse® POWR-GARD® Fast Acting Fuse, Current Limiting, Series: LDC, Non-Indicating, 300 A, 600 VAC/VDC, 50/200 kA Interrupt, Class: L, 10 s Response, Knife Blade Terminal, Bolt Mounting, Cartridge Body, Melamine, 2-1/2 in Dia x 8-5/8 in L Body

Application

Solar Inverter and Array Protection, Ups Protection Especially For Large Battery Circuits, DC Distribution and Variable Speed Drives and Mass Transit Systems Applications

Standards

UL File No. E81895 | CSA LR29862 | PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer

Features

  • 600 VAC/VDC rated, all purpose class L fuse reduces inventory requirements because the need for special fuses is eliminated
  • UL Listed 200000 A.I.R. AC - 50000 A.I.R. DC - reliable interruption of all over currents upto their ratings, minimizes the need for time-consuming and expensive short circuit studies
  • Moderate time delay - four seconds time delay at 500 percent current provides adequate time-delay for many AC applications and most DC applications, they will withstand most harmless overloads or line surges, if your needs exceed the LDC capabilities, consider the use of KLPC fuses for AC applications
  • Selective coordination - LDC series fuses coordinate well with all Littelfuse fuses rated 600 A or less, a combination of LDC and IDSR series fuses provide a complete 600 V rated DC system
  • Extremely current limiting - maximum current limitation reduces damage to circuits and equipment under short circuit conditions, stops damaging short circuits faster than any mechanical protective device
  • Silver plated copper caps
  • 200 kA at 600 VAC, 50 kA at 600 VDC interrupting rating

Specifications

Amperage Rating:300 A
Body Size:2-1/2 in Dia x 8-5/8 in L
Body Type:Cartridge
Class:L
Country of Origin:MX
Indicating/Non-Indicating:Non-Indicating
Interrupt Rating:50/200 kA
Material:Melamine
Mounting Type:Bolt
Response Time:10 s
Series:LDC
Terminal Type:Knife Blade
Voltage Rating:600 VAC/VDC
