LDS5IG10-A PAN

LDS non-metallic surface raceway will be a one piece, solid raceway used to route, protect and conceal data network, voice or power cabling. The raceway shall be listed as suitable for use in applications having up to 600 volts between conductors by underwriters laboratories, inc. per standard 5A when screw secured with mounting straps and per installation instructions. The raceway shall be manufactured from impact resistant material with flammability rating of UL94V-0. A full complement of power, 1 in bend radius control and standard snap-on fittings must be available. All fittings and boxes shall be tamper resistant to prevent unauthorized access to cables. LDS raceway finish shall be pure color and will resist scratches and dents and will not peel or corrode.

Panduit® Pan-Way™ Non-Metallic Raceway, Power Rated, Series: LDS, 10 ft Length, 1.01 in Width, 0.55 in Height, 600 VAC, 1 Channels, Coaxial/Data Grade/Electrical/Fiber Optic Cable, Adhesive Back, Non-Hinged/Single Channel Cover, Surface Mounting, PVC, International Gray
