Name: LFPHV0001ZXID LIT
Brand: Littelfuse
SKU: LFPHV0001ZXID LIT
Availability: OutOfStock

LFPHV0001ZXID LIT

Actual Product May Vary From Image

Product Details

Manufacturer:

Littelfuse

Manufacturer part number:

LFPHV0001ZXID

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Littelfuse®

Type

Indicating

Description

Littelfuse® POWR-GARD® Fuse Holder, Indicating, Series: LFPHV, 1000 VDC, 30 A, 4 W, 1 Pole, Class: RK5, Pressure Plate, 6 to 4 AWG Wire, 1.496 in Fuse Length, 0.394 in Fuse Dia, Thermoplastic, 3.28 in H x 0.701 in W x 2.47 in D

Standards

UL 94 V-0 Flammability Rating | CE Certified | CSA Certified | IEC 60269

Features

Finger safe design offers personnel protection
Compact design
35 mm DIN rail mountable
No fuse pullers or tools required for fuse removal
Lead free
33 kA SCCR rating

Specifications

Amperage Rating:	30 A
Class:	RK5
Connection Type:	Pressure Plate
Country of Origin:	DE
Dimensions:	3.28 in H x 0.701 in W x 2.47 in D
Fuse Diameter:	0.394 in
Fuse Length:	1.496 in
Material:	Thermoplastic
Number of Poles:	1
Power Rating:	4 W
Series:	LFPHV
Voltage Rating:	1000 VDC
Wire Size:	6 to 4 AWG
