Actual Product May Vary From Image

LL14MGT-020 GAT

Name: LL14MGT-020 GAT
Brand: Gates
SKU: LL14MGT-020 GAT
Price: 42.74 USD
Availability: InStock

Poly Chain™ GT Carbon Extended Length

Manufacturer: Gates

Manufacturer part number: LL14MGT-020

Availability: Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
284	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$42.74

Qty:

Product Details

Brand Name

Gates

Alternate Supplier #

93021300

Description

A comprehensive range of open-ended belt constructions which can easily be cut to the required length. Long-length open-end synchronous belts are especially suited for linear movement, positioning and conveyor applications. Available in Poly Chain® GT™ Carbon™, PowerGrip™ GT2™, PowerGrip HTD™ and PowerGrip Timing constructions.

Features

Durable polyurethane construction resists chemicals, oil, pollutants and abrasion. Robust carbon tensile cord combines minimal stretch with extraordinary strength and load carrying capacity. Nylon tooth facing reduces friction and eliminates the need for lubrication. High positioning accuracy, making the belt ideally suited for applications with repetitive movements; length stability due to the use of high modulus tensile members. Easy to attach with clamping fixtures; maintenance-free, clean solution for roller chain drive conversion; no lubrication or retensioning required.

Specifications

Belt Back Side:	Smooth
Belt Height (in):	0.394
Belt Height (mm):	10.2
Belt/Slab:	Belt
Color:	Black
Cord Material:	Carbon
Country of Origin:	US
End:	Endless
Fabric Material:	Nylon
GC Base Product:	Poly Chain® GT® Carbon™ Extended Length Linear Belting - 14mm Pitch
Harmonized Tariff Code:	3926.90.5700
Material:	Polyurethane
Max Temp (°C):	+85
Max Temp (°F):	+185
Min Temp (°C):	-54
Min Temp (°F):	-65
Number of Teeth:	315
Pitch (in):	0.552
Pitch (mm):	14
Proposition 65:	NO
Section:	14M
Sided:	Single Sided
Sprock Comptab:	Poly Chain GT
Standard Width:	YES
Stat Conductive:	No
Tooth Form:	Curvilinear
Tooth Height (in):	0.236
Tooth Height (mm):	6
Width (in):	0.787
Width (mm):	20
