LL2MR06 GAT

Name: LL2MR06 GAT
Brand: Gates Corporation
SKU: LL2MR06 GAT
Price: 4.56 USD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Gates Corporation

Manufacturer part number:

LL2MR06

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

$4.56 / EA

Description

Brand Name

Gates®

Type

Long Length

Description

Long-length PowerGrip® GT®2 belting is a cost effective, low maintenance drive alternative. The PowerGrip® GT®2 belt tooth is designed for use with a specific sprocket groove profile. The sprocket groove-belt tooth combination increases capacity, while improving registration.

Gates® PowerGrip® GT®2 Synchronous Belt, Long Length, Series: 9396, 2 mm Pitch, 300 ft Overall Length, 6 mm Width, -35 to 180 deg F, Curved Tooth Profile, Neoprene, Fiberglass Reinforced Material

Application

For linear movement, positioning and conveying applications

Standards

RMA Standard

Features

Fiberglass tensile cord provides high strength, excellent flex life and high resistance to elongation
Nylon tooth facing provides a durable wear surface for long service life
Eliminates lubrication and re-tensioning to reduce maintenance and labor as compared to roller chain drives
Neoprene body provides protection against grime, grease, oil and moisture
PowerGrip® GT®2 belt/sprocket combinations match or exceed the positional accuracy of PowerGrip® timing belt/pulley systems
PowerGrip® GT®2 has more tooth ratchet resistance than HTD®
The PowerGrip® GT®2 belt tooth is designed for use with a specific sprocket groove profile
The sprocket groove-belt tooth combination increases capacity, while improving registration
Long length PowerGrip® GT®2 belting is a cost effective, low maintenance drive alternative

Specifications

Country of Origin:	US
Material:	Neoprene
Overall Length:	300 ft
Pitch:	2 mm
Reinforced Material:	Fiberglass
Series:	9396
Temperature Range:	-35 to 180 deg F
Tooth Profile:	Curved
Width:	6 mm
