LPSC002ID LIT

Littelfuse® POWR-SAFE LPSC002ID Dead Front Indicating Fuse Holder With Blown Fuse Indicator, 600 VAC/VDC, 30 A, Class: CC, 14 to 8 AWG Wire, 2 Poles
Manufacturer: Littelfuse
Manufacturer part number: LPSC002ID
Availability: Ships in 4-6 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$85.18

Product Details

Brand Name

Littelfuse®

Type

Dead Front Indicating

Description

Littelfuse® POWR-SAFE in dead front in holders provide optimum protection to personnel. Indicating and non-indicating versions are available in 1, 2, 3 or 4 poles for class CC and midget fuses.
Littelfuse® POWR-SAFE Fuse Holder, Dead Front Indicating, Series: LPSC, 600 VAC/VDC, 30 A, 2 Pole, Class: CC, Pressure Plate Connection, 14 to 8 AWG Wire, DIN Rail Mounting, For Use With: Class CC Fuse, Thermoplastic, 1.4 in W x 2.33 in D x 3.06 in H Dimensions

Standards

UL E14721 | CSA LR7316 | PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer.

Features

  • Provide optimum protection to personnel
  • Meets dead front requirements
  • Easy installation and removal of fuses
  • No special fuse pullers or tools required
  • Compact design
  • Ventilated design for cooler operation
  • Indicates above 80 V
  • 14 to 8 AWG Cu wire size
  • 35 mm DIN rail mounting

Specifications

Amperage Rating:30 A
Class:CC
Connection Type:Pressure Plate
Country of Origin:CN
Dimensions:1.4 in W x 2.33 in D x 3.06 in H
Material:Thermoplastic
Mounting Type:DIN Rail
Number of Poles:2
Series:LPSC
Suitable For Use With:Class CC Fuse
Voltage Rating:600 VAC/VDC
Wire Size:14 to 8 AWG
