LR60 HWD

Name: LR60 HWD
Brand: Hubbell Wiring Device-Kellems
SKU: LR60 HWD
Price: 34.30 USD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Hubbell Wiring Device-Kellems

Manufacturer part number:

LR60

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

$34.30 / EA

Description

Brand Name

Wiring Device-Kellems

Type

Heavy Duty Industrial Grade Non-Metallic Replacement Standard Watertight

Description

Wiring Device-Kellems Replacement Locking Ring Kit, Heavy Duty Non-Metallic Standard Watertight, For Use With: Insulgrip® 60/63 A IEC Plug, Connector and Inlet, IP67 Suitability, -40 to 75 deg C Operating Temperature, Composite, Gray

Application

Industrial Applications

Standards

CSA Certified | UL Listed | RoHS Compliant

Features

Neoprene gasket
Withstand 3000 VAC dielectric voltage
Certified for current interrupting at full rated current
Suitable for use on a circuit capable of delivering not more than 10,000 rms symmetrical amperes at the voltage rating of the receptacle
In accordance with UL 746C impact resistance
IP67 ingress protection
UL94-5VA and V-0 classification flammability
-40 to 75 deg C continuous operating temperature
All materials are UV stabilized
Where an IEC configuration is required but water resistance is not necessary, low profile pin and sleeve can make the connection

Specifications

Color:	Gray
Country of Origin:	US
Material:	Composite
Specifications:	600 VAC rms Max Working Voltage
Suitable For Use With:	60 and 63 A Plugs, Connectors and Inlets and IEC Devices
