M20252 OZG

Picture of M20252 OZG
Actual Product May Vary From Image

Product Details

Manufacturer:
Appleton
Manufacturer part number:
M-2025-2
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Expected Leadtime 7 days
Estimated dates are contingent upon manufacturer stock.
Log in for more accurate pricing
$617.94 / EA

Description

Brand Name

O-Z/Gedney

Type

Type M Space Maker

Description

O-Z/Gedney Cable Support, Type M Space Maker, 2 in Size, For Use With: IMC/Rigid Conduit and EMT, Specifications: 18 to 8 AWG, 6 to 1/0 AWG, 2/0 to 4/0 AWG, 4/0 AWG to 750 kcmil AL/Cu Conductor, Malleable/Ductile Iron, Hot Dipped Galvanized, 3 in Dia x 2-5/8 in H Dimensions

Application

Indoor and Junction Box Applications

Standards

Buy American Act Compliant | UL 514B | UL File No. E11853 | ANSI Specified | NEC 300-19

Features

  • Use with all types of insulations at all voltages
  • This fitting is similar to the type R support, except that it is threaded at the top to allow fastening to a cabinet (1/4 max thickness) with standard locknuts or threading into tapped (NPT) openings

Specifications

Country of Origin:US
Dimensions:3 in Dia x 2-5/8 in H
Finish:Hot Dipped Galvanized
Material:Malleable/Ductile Iron
Size:2 in
Specifications:18 to 8 AWG, 6 to 1/0 AWG, 2/0 to 4/0 AWG, 4/0 AWG to 750 kcmil AL/Cu Conductor
Suitable For Use With:IMC/Rigid Conduit and EMT
