P3U239N LBB

Name: P3U239N LBB
Brand: Rexnord
SKU: P3U239N LBB
Price: 321.35 USD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Rexnord

Manufacturer part number:

P3U239N

CBT Inventory

Vendor Inventory

Availability:

Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

$321.35 / EA

Description

Brand Name

Link-Belt®

Type

Standard-Duty

Description

200 series standard duty ball bearing units provide a versatility of application arrangements for carrying shafts with radial or combination radial and thrust loads. They are designed for general purpose industrial machinery, conveyors, chain, belt drives, fans, blowers, power transmission and many other applications.

Link-Belt® Pillow Block Ball Bearing, Standard-Duty, Series: 200, 2-7/16 in Bore, 7-1/2 in Bolt Center-to-Center Length, 2-11/16 in Base to Bore Centerline, 9-1/2 in Overall Length, 2-1/2 in Overall Width, 5-3/8 in Overall Height, Two-Bolt Base Mounting, Round Bore, 2-3/8 in Base Width, Set Screw Locking Device, Single Lip Seal, Non-Expansion (Fixed) Expansion, 11840 lb Dynamic/8080 lb Static Load, 225 deg F, 4000 rpm Maximum, Cast Iron, Powder Coated

Application

Aggregates, Agriculture, Air Handling, Package Handling, Construction and Shipping Industries

Standards

ANSI/ABMA STD 9

Features

Precision alignable ball bearings of deep groove construction for high capacity and high precision applications
Compact, 1-piece housing provides excellent mounting support
Relubricatable bearing
Standard backing
Integral bearing seals
Wide inner ring for increased shaft stability

Specifications

Base to Bore Centerline:	2-11/16 in
Base Width:	2-3/8 in
Bolt Center-to-Center Length:	7-1/2 in
Bore Diameter:	2-7/16 in
Bore Type:	Round
Expansion Type:	Non-Expansion (Fixed)
Finish:	Powder Coated
Load Capacity:	11840 lb Dynamic/8080 lb Static
Locking Device:	Set Screw
Material:	Cast Iron
Maximum Speed:	4000 rpm
Mounting Type:	Two-Bolt Base
Overall Height:	5-3/8 in
Overall Length:	9-1/2 in
Overall Width:	2-1/2 in
Seal Type:	Single Lip
Series:	200
Temperature Rating:	225 deg F
