RRS100 HUB 1-1/8 1/4X1/8KW LOV

Lovejoy® 68514438156 Type RRS Style 1 Jaw Coupling Hub With Keyway and Setscrew, RRS100 Coupling, 1-1/8 in Dia Bore, 1.38 in L Through Bore, 2.53 in Dia Hub, Sintered Iron
Manufacturer: Lovejoy
Manufacturer part number: 68514438156
Availability: Ships in 2-4 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$69.58

Product Details

Brand Name

Lovejoy®

Type

Type RRS Style 1

Description

Lovejoy® Jaw Coupling Hub, Type RRS Style 1, RRS100 Coupling, 1-1/8 in Bore, 2.53 in Diameter Hub, 1.97 in Hub Length, 1/4 in W x 1/8 in D Keyway, 3600 rpm Maximum, 1.38 in Length Through Bore, 5/16-18 Screw, Sintered Iron, Metallic/Gray

Standards

ECCN EAR99

Specifications

Bore Diameter:1-1/8 in
Country of Origin:US
Coupling Size:RRS100
Finish:Metallic/Gray
Hub Diameter:2.53 in
Hub Length:1.97 in
Keyway Size:1/4 in W x 1/8 in D
Length Through Bore:1.38 in
Material:Sintered Iron
Maximum Speed:3600 rpm
Screw Size:5/16-18
