Martin S1628 External Tooth Reborable Stock Spur Gear, 16 Diametral Pitch, 14.5 deg Pressure Angle, 1/2 in W Face, 28 Teeth, 1-3/4 in Dia Pitch, 1/2 to 7/8 in Dia Bore, Steel
Manufacturer: Martin Sprocket & Gear
Manufacturer part number: S1628
Availability: Ships in 2-4 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$41.95

Product Details

Brand Name

Martin

Type

External Tooth Reborable

Description

Martin stock spur gears are available in five different styles. Steel gears are furnished in plain style and plain style with hub. Cast gears are furnished, plain with hub, web with lightening holes, and spoke. Cast gears are machined on all operating surfaces. Martin cast gears are cast with a larger hub to provide extra strength and to allow for larger bores. Spur gears are stocked in both 14-1/2 and 20 deg pressure angles.
Martin Stock Spur Gear, External Tooth Reborable, 1/2 to 7/8 in Bore Dia, 1-7/8 in Outside Dia, 28 Teeth, 16 Diametral Pitch, 1-3/4 in, 1/2 in Face Width, Type B, 1-1/2 in Hub Dia, 1/2 in Hub Projection, 1 in Overall Length, 14.5 deg Pressure Angle, Steel

Specifications

Bore Diameter:1/2 to 7/8 in
Country of Origin:US
Diametral Pitch:16
Face Width:1/2 in
Hub Diameter:1-1/2 in
Hub Projection:1/2 in
Hub Type:Type B
Material:Steel
Number of Teeth:28
Outside Diameter:1-7/8 in
Overall Length:1 in
Pitch Diameter:1-3/4 in
Pressure Angle:14.5 deg
