SB22224/C3W33SS BLT

Picture of SB22224/C3W33SS BLT
Actual Product May Vary From Image

Product Details

Manufacturer:
Bearings Limited
Manufacturer part number:
SB22224/C3W33SS
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
1-2 weeks.
Estimated dates are contingent upon manufacturer stock.
Log in for more accurate pricing
$1,029.27 / EA

Description

Brand Name

TRITAN®

Type

Straight Bore

Description

TRITAN® Spherical Roller Bearing, Straight Bore, Series: SB 22200, 120 mm Bore, 215 mm OD, 1 Row, 58 mm Width, Sealed Closure, 140606 lb Load, Steel Bearing, 1948 rpm Grease Maximum, -20 to 212 deg F

Standards

AISI/SAE 52100

Features

  • Single row design offering increased load capacity
  • Sealed to keep contamination out and lubricant in
  • Dimensionally interchangeable with double row unsealed designs
  • W33 oil hole and groove in OD
  • 113303 lb dynamic/140606 lb static load

Specifications

Bearing Material:Steel
Bore Diameter:120 mm
Closure Type:Sealed
Load Capacity:140606 lb
Maximum Speed:1948 rpm Grease
Number of Rows:1
Outside Diameter:215 mm
Series:SB 22200
Temperature Rating:-20 to 212 deg F
Width:58 mm
