SCS500-6 PAN

Name: SCS500-6 PAN
Brand: Panduit
SKU: SCS500-6 PAN
Price: 22.65 USD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Panduit

Manufacturer part number:

SCS500-6

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

$22.65 / EA

Description

Brand Name

Panduit®

Type

Type SCS

Description

Panduit® Pan-Term® splices are designed and manufactured for fast assembly and long reliable performance. As the demand for splices increases, it becomes essential to provide a complete system for termination products. We provide an extensive line of tooling designed specifically to provide optimum performance when used as a system for terminating.

Panduit® Pan-Lug™ Compression Butt Splice, Series: SCS, Stranded Copper Conductor, 500 kcmil Conductor, 2.87 in Length, Standard Barrel, 0.84 in ID x 1.05 in OD Barrel, 35 kV, 1-3/8 in L Wire Strip, 90 deg C, Copper, Brown, Electro TiN Coated

Application

For wide wire range taking capability when crimped with Panduit® Uni-Die™ dieless crimping tools

Standards

Features

Color coded barrels marked with Panduit® and specified competitor die index numbers for proper crimp die selection
Internal wire stops to prevent over insertion of conductor
Tin plated to inhibit corrosion
UL listed and CSA certified to 35 kV and temperature rated to 90 deg C when crimped with Panduit® and specified competitor crimping tools and dies

Specifications

Barrel Size:	0.84 in ID x 1.05 in OD
Barrel Type:	Beveled/Seamless/Standard
Color:	Brown
Conductor Size:	500 kcmil
Conductor Type:	Stranded Copper
Country of Origin:	MX
Finish:	Electro TiN Coated
Length:	2.87 in
Material:	Copper
Series:	SCS
Specifications:	1-3/8 in L Wire Strip
Temperature Rating:	90 deg C
Voltage Rating:	35 kV
