SNAP2172ISC HWD

Picture of SNAP2172ISC HWD
Actual Product May Vary From Image

Product Details

Manufacturer:
Hubbell Wiring Device-Kellems
Manufacturer part number:
SNAP2172ISC
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Ships in 4-6 days.
Estimated dates are contingent upon manufacturer stock.
Log in for more accurate pricing
$27.03 / EA

Description

Brand Name

Wiring Device-Kellems

Type

Decorator Duplex Extra Heavy Duty Split Circuit

Description

SNAPConnect® devices offer superior installation efficiency for new construction and renovations, while delivering safe, reliable connections. Instead of conventional wiring methods, SNAPConnect® modular connector is installed during rough-in in leu of pigtails. Once the walls are up, the protective covering is removed and the terminal is simply snapped into the SNAPConnect® device for a consistent connection every time. Once installed, SNAPConnect® modular design enables simple device change-out by maintenance personnel.
Wiring Device-Kellems, SNAP2172ISC, Straight Blade Receptacle, Decorator Duplex Extra Heavy Duty Split Circuit, 125 VAC, 15 A, 1/2 hp, 2 Pole, 3 Wires, 5-15R NEMA Rating, Hospital Grade, IP20 Enclosure, -40 to 75 deg C, Pigtail Lead Terminal, Nylon, Ivory, 3.28 in L x 1.64 in W x 1.1 in H Dimensions

Application

Hospitals, Healthcare Facilities, Labs/Imaging, Long Term Care and Commercial Construction Applications

Standards

CSA C22.2 No. 42 File 285 | Federal Specification WC596 | UL Listed to UL498 File No. E2186, BAA Compliant | UL94 V-2 Flammability Rating | NEMA WD6

Features

  • Audible SNAP, indicates solid connection
  • Reduces installation time
  • Fully insulated design
  • Modular wiring system eliminates screw terminals
  • Speeds installation and trim out
  • Clear polycarbonate terminal housing to inspect contacts
  • Abuse resistant nylon for extra heavy use applications
  • Stainless steel auto ground

Specifications

Amperage Rating:15 A
Color:Ivory
Country of Origin:US
Dimensions:3.28 in L x 1.64 in W x 1.1 in H
Enclosure:IP20
Grade:Hospital
Horsepower:1/2 hp
Material:Nylon
NEMA Rating:5-15R
Number of Poles:2
Number of Wires:3
Temperature Rating:-40 to 75 deg C
Terminal Type:Pigtail Lead
Voltage Rating:125 VAC
