TB81215F3 ACM

Acme TB Series Industrial Control Transformers are especially designed to accommodate the momentary current inrush caused when electromagnetic components are energized without sacrificing secondary voltage stability beyond practical limits. Acme TB Series transformers are dry-type, step-down transformers with the secondary control circuit isolated from the primary line circuit to assure maximum safety. Voltage regulation of Acme TB Series transformers exceeds standards recommended by the National Electrical Manufacturers Association. Secondary circuit voltage drop between no-load and momentary overload remains exceptionally low. This excellent secondary circuit voltage regulation assures reliable operation of electromagnetic components and may permit the use of a smaller and less expensive industrial control transformer.

Acme Electric® Control Transformer, Industrial Open Style, 240/480 VAC Primary, 120 VAC Secondary, 500 VA Power, 50/60 Hz Frequency, 1 ph, 4.17 A Maximum, Screw Connection, Panel Mounting, 130 deg C Insulation, 80 deg C, 4.47 in H x 5.25 in W x 6.3 in D Dimensions
