Picture of THQL1120 ABB
Actual Product May Vary From Image

THQL1120 ABB

THQL 1 POLE 120/240V 10K IC 20 AMP
Manufacturer: ABB
Manufacturer part number: THQL1120
Availability: Expected Leadtime 24 days
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CRUSH BEARINGS & DRIVES - LEXINGTON
22 0 0
CRUSH BEARINGS & DRIVES - LOUISVILLE CBT - Sidney
0 0
Loading...
$7.49

Product Details

Type

Q-Line Plug-In

Description

Q Line circuit breakers are one-inch wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications in load centers or lighting panels. All Q Line circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. Q Line breakers can be ordered with auxiliary contact and shunt trip accessories, and can be ordered for use in HID applications.The THQL1120 breaker features 1 pole, an ampere rating of 20 A, an interrupting rating of 10kAIC, and a voltage rating of 120/240V

Application

Thermal Magnetic

Standards

E11592

Features

Q Line circuit breakers are one-inch wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications in load centers or lighting panels. All Q Line circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. Q Line breakers can be ordered with auxiliary contact and shunt trip accessories, and can be ordered for use in HID applications.The THQL1120 breaker features 1 pole, an ampere rating of 20 A, an interrupting rating of 10kAIC, and a voltage rating of 120/240V.

Specifications

120 VAC Interrupting Rating:10 KAIC
120/240 VAC Interrupting Rating:10 KAIC
Amperage Rating:20 A
Circuit Breaker Type:Residential
Continuous Current Rated:Standard
Control Power:No
Country of Origin:UKN
Current Limiter:No
Current Metering:No
Device type 1:Q-Line Plug-In
Frame:Q-Line
GO Schedule:R8
Harmonized Tariff Code:8536200020
Instantaneous:Fixed
Interrupt Rating:10kA@120 Vac / 10kA@120/240 Vac
Interrupting Capacity Rating:10 kAIC
Line Lug:Without
Load Lug:With
Load Rating:HACR / SWD
Long Time:Fixed
Number of Poles:1
Protective Relays:No
Suitable for Reverse Feed:Yes
Trip Range:Non-Interchangeable
Trip Type:LI
Trip Unit Included:Yes
UL:Yes
Video:"<a href=""https://www.youtube.com/embed/dh3pElJ-RA8"" target=""_blank"">We are Industrial Solutions</a>"
Voltage Rating:120/240 V

Resources

Spec SheetVideo
