TRA-815 KOY

Koyo TRA-815 Double Direction Thrust Washer, 12.7 mm ID x 23.8 mm OD, 0.81 mm W
Manufacturer: Koyo Bearings
Manufacturer part number: TRA-815
Availability: Ships in 3-5 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$1.04

Product Details

Brand Name

Koyo

Type

Double Direction

Description

Ideally, a thrust washer should be stationary with respect to and piloted by its supporting or backing member whether or not this is an integral part of the shaft or housing. There should be no rubbing action between the thrust washer and any other machine member. The economics of design, however, often preclude these ideal conditions and thrust washers must be employed in another manner. In such cases, design details should be determined in consultation with your representative.
Koyo Thrust Washer, Double Direction, 12.7 mm ID, 23.8 mm OD, 0.81 mm Width, For Use With: NTA Series Needle Roller Bearing and Cage Assembly

Features

  • Dimensions for bore and OD of thrust assemblies and washers are nominal
  • Thrust washers burnished at least one quarter of bore area (remainder is rough breakaway finish)
  • OD finish of washers will be as blanked

Specifications

Inside Diameter:12.7 mm
Outside Diameter:23.8 mm
Suitable For Use With:NTA Series Needle Roller Bearing and Cage Assembly
Width:0.81 mm
