UB6X125MA OZG

Picture of UB6X125MA OZG
Actual Product May Vary From Image

Product Details

Manufacturer:
Appleton
Manufacturer part number:
UB6X-125MA
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Ships in 5-7 days.
Estimated dates are contingent upon manufacturer stock.
Log in for more accurate pricing
$174.34 / EA

Description

Brand Name

O-Z/Gedney

Type

Explosionproof

Description

O-Z/Gedney Conduit Body, Explosionproof, Type UB Body Type, 1-1/4 in Hub, 2 Hubs, 40 cu-in, Mogul, Tapered/Threaded, Copper-Free Aluminum, Epoxy Powder Coated, 10.25 in L x 2.38 in W x 4.13 in H

Application

For pulling fittings, make bends in conduit system; provide openings for splicing, connect and change direction of conduit runs, allow connections for straight, branch runs and 90 deg bends, permit access to conductors for maintenance of rigid conduit and IMC, wet location

Standards

UL 514A | UL File No. E18095 | CSA C22.2 File No. 18 | CSA File No. 9795 | Federal Specification A-A-50563 | Class 1, Division 2 Per NEC section 501-4(B) | NEC section 314.28 | NEMA FB-1/FB-2.1

Features

  • Meets NEC section 314.28 rule for 6X or 8X the conduit trade size between hubs
  • Mogul design for large and heavy conductors
  • Raintight when used with gasketed covers
  • Smooth integral hub bushings protect conductor insulation
  • 45 deg hub placement
  • Access opening back
  • With captive stainless steel screws and built-in cable pulling rollers

Specifications

Body Type:Type UB
Capacity:40 cu-in
Connection Type:Tapered/Threaded
Country of Origin:MX
Dimensions:10.25 in L x 2.38 in W x 4.13 in H
Finish:Epoxy Powder Coated
Form:Mogul
Hub Size:1-1/4 in
Material:Copper-Free Aluminum
Number of Hubs:2

Products Specifications

Brand Name
O-Z/Gedney
Size
1 1/4 in
