Actual Product May Vary From Image

VWDM3542 BLD

Name: VWDM3542 BLD
Brand: Baldor Reliance
SKU: VWDM3542 BLD
Price: 891.52 USD
Availability: OutOfStock

.75HP,1750RPM,3PH,60HZ,56C,3516M,TENV,F1

Manufacturer: Baldor Reliance

Manufacturer part number: VWDM3542

Availability: Ships in 1-3 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$891.52

Qty:

Product Details

Brand Name

Baldor-Reliance

Type

AC Motors

Description

Baldor Electric; Washdown Motor; Phase: 3 PH; Torque Rating: 2.24 LB-FT Full Load, 9.58 LB-FT Break Down, 6.13 LB-FT Pull-Up, 75 LB-FT Locked-Roter At 460 V, 60 HZ, 0.75 HP; Horsepower: 0.75 HP; Speed Rating: 1750 RPM; Voltage Rating: 230/460 VAC; Frequen

Application

Wash Down

Features

.75HP,1750RPM,3PH,60HZ,56C,3516M,TENV,F1

Specifications

Base:	No mounting
Country of Origin:	US
Duty:	Continuous
Enclosure:	TENV
Frame:	56
Frequency Rating:	60 Hz
Full Load Current:	1.2 A; 2.4 A
Horsepower:	0.750 hp
Insulation Class:	F
Mounting:	F1
NEMA Design:	B
NEMA Nominal Efficincy:	80.00%
Phase:	Three Phase
Power Factor:	74
Rotation:	Reversible
Service Factor:	1.25
Speed Rating:	1,750 rpm
Voltage Rating:	230 V; 460 V

Resources

Tech Drawing Spec Sheet Warranty
