ST6003PYG FER

Picture of ST6003PYG FER
Actual Product May Vary From Image

Product Details

Manufacturer:
Mersen
Manufacturer part number:
ST6003PYG
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Expected Leadtime 30 days
Estimated dates are contingent upon manufacturer stock.
Log in for more accurate pricing
$293.99 / EA

Description

Brand Name

Mersen

Description

Surge-Trap® modular surge protective device (SPD) is a no-fuse, fail safe surge suppressor featuring MERSEN's patented TPMOV® technology inside. UL 1449 4th Edition approved, it is DIN rail mountable featuring a fail safe self-protected design, visual indicator, and a small footprint. A remote indicator option provides status to critical control circuitry. The Surge-Trap modular SPD has a high short circuit rating and a thermally protected MOV, which eliminates the need for additional overcurrent protection devices.
Mersen Surge-Trap® Surge Protective Device, Series: ST Series, 347/600Y VAC, 50/60 Hz, 3 Pole, 4 Wires, 200 kA Short Circuit Current Rating, 50 kA Peak Surge, 20 kA Nominal Discharge, Modes of Protection: L-N/L-G/L-L, <25 ns Response, 3 Phase, Environmental Conditions: -40 to 85 deg C Operating Temperature, -40 to 85 deg C Storage Temperature, IP20, DIN Rail Mount, Box Terminal, Polyethylene Terephthalate, 3.58 in L x 2.7 in W x 2.1 in D

Application

AC/DC Distribution, Power Supplies, Industrial Automation, Telecommunications, Motor Controls and Starter Systems, Programmable Logic Controller, Power Transfer Equipment, HVAC, AC Drives, UPS Systems, Security Systems, IT/Data Centers and Medical Equipment

Standards

RoHS Compliant | UL 1449 File No. E210793 | IEC 61643-1 | ANSI/IEEE C62.41 | CE Certified | cULus Recognized | UL94 V0 Flammability Rating

Features

  • Easy installation or retrofit DIN rail mountable
  • Fail safe/self protected design
  • IP20 fingersafe design
  • Visual indicator
  • Small footprint
  • No additional overcurrent protection devices needed
  • Without N-G mode

Specifications

Country of Origin:MX
Dimensions:3.58 in L x 2.7 in W x 2.1 in D
Electrical Ratings:347/600Y VAC
Enclosure Type:IP20
Environmental Conditions:-40 to 85 deg C Operating Temperature, -40 to 85 deg C Storage Temperature
Frequency Rating:50/60 Hz
Material:Polyethylene Terephthalate
Modes of Protection:L-N/L-G/L-L
Mounting Type:DIN Rail
Nominal Discharge Current:20 kA
Number of Poles:3
Number of Wires:4
Peak Surge Current:50 kA
Phase:3
Response Time:<25 ns
Series:ST Series
Short Circuit Current Rating:200 kA
Terminal Type:Box
